Specialized Gen 4 Levo: Things to Know
- Posted on
- By Troy Treaccar & Nate Braks
We have put together a short, digestible, overview of the NEW Gen 4 Levo. All killer, no filler.
DESIGN
-
160mm Fork Travel; 150 Rear Travel (tested up to 180mm Fork Travel without voiding warranty). Rear Shock is Genie, 210 x 55. Compatible with many after-market shocks.
-
Seattube is one degree steeper than the Gen 3 Levo – intended for tech climbing positions – and deeper. 200mm dropper post is stock.
-
Geometry adjustment in 3 spots – headtube, shock, chainstay. Mullet only wheelset.
-
Emergency SWAT storage above battery. Spare tube, tools, etc.
MOTOR
-
101nm torque and 666 watts. S-Work is 111nm Torque and 720 watts. Note: Gen 3 is 90nm and 560 watts.
-
20% smaller – but similar weight.
-
All gears, no belt. All steel parts with protective coating (many other competitors have some plastic parts that expand/contract under heat and fail).
-
Noise is less than Gen 3 and consistent throughout ride.
BATTERY
-
3 options – 840wh (comes on all models), 600wh (1kg lighter), 280wh range extender. Note: Bike power is reduced when running only off range extender.
-
Much shorter than Gen 4 – can fit in backpack, lower center of gravity, makes the motor casing smaller.
-
50 volt system – instead of 36 volt. Increases range.
-
Will power SRAM AXS derailleur.
-
Smart Charger – sold separately (included with S-Works). Charging modes are Eco, Standard, Fast and 80% (for storage). Fast mode charges the bike to 80% in one hour.
PERFORMANCE
-
Class 1 or 3. Adjustable by rider. Class 3 (28 mph) is intended as “Trailhead Shuttle”.
When in Class 3, the MM will be announcing Class 3. Shop can disable this feature in TS.
-
Larger range of cadence to get full power out of motor – i.e. more torque and power at lower cadence for tech climbing.
-
Additional motor tune option called “Overrun”. This is for tech climbing, motor continues longer when pedals stop. Clear rocks and roots that would cause pedal strikes.
SERVICE
-
Free pivot bearings for first owner (parts only).
-
Genie shock is serviced with standard Float X kit.
-
MM does not require a Torx to remove.
-
“Triple Sealed” Connections. Three O-rings. Note: Gen 3 is Double Sealed.
INTERFACE
-
Support tunes and micro tune can be adjusted on bike (not just via App).
-
Auto pair mode on app – app turns on and starts recording when the bike turns on.
-
Apply “Find My” works even without battery installed.
